Aesthetically designed LED post tops for pathways, gardens and promenades with Pressure die-cast aluminium housing. Clear injection moulded PC diffuser for uniform lighting with IP66 degree of protection.
The Eveready Advantage
Aesthetic design for elegant outdoors.Pressure die-cast aluminium housing for enhanced finish.Clear PC diffuser for uniform lighting.
Features
Aesthetic design for elegant outdoors.Pressure die-cast aluminium housing for enhanced finish.Clear PC diffuser for uniform lighting.
Specifications
| Housing & Finish | PDC aluminium Housing with epoxy grey finish |
| Power Factor | ≥ 0.95 |
| Total Harmonic Distortion | ≤ 10% |
| Surge Protection | Up to 4kV inbuilt 10kV external |
| Input Voltage | 240V 50Hz |
| Operating Voltage Range | 140V - 240V AC |
| Average life span at L70B50 | 36000 Hours |
| Operating Temperature | -10℃ to +50℃ |
| Mounting arrangement | Pole Mounting |
| Ingress protection & Impact resistance | IP66, IK-08 |
Product Ordering Details
| Ordering Code | Product Cat Ref | Input Power (W) | CCT | CRI | Luminous Flux (Lumens) | Case Lot | Weight |
|---|---|---|---|---|---|---|---|
| 6L1P308HA36 | LEDPOST036I3-02C | 36 | 3000K | >80 | 3240 | 1 | 1.55 |
| 6L1P308HC45 | LEDPOST045I3-02C | 45 | 3000K | >80 | 4050 | 1 | 1.55 |
| 6L1P578HA45 | LEDPOST045I5-02C | 45 | 5700K | >80 | 4500 | 1 | 1.55 |
Raise a Query
Due To Continuous Technological Improvements And Design Requirements, Our Products Are Subject To The Up-Gradation Which May Result In Change Of Design, Shape, And Technical Data As Appearing. Please Connect With Our Authorized Dealer Or Sales Person For Latest Lighting Solutions.
