Perforbay N & Perforbay N PC-200W
Perforbay N made with pressure die-cast aluminium square housing given in epoxy black powder coated finish for better aesthetics. Clear toughened glass fixed weatherproof gasket with SS screws provides uniform light distribution and protection. Anti-vibration rubber & eye bolt-nut along with counter pin is provided for easy & safe installation. These highbay lights comes with unique design for better heat dissipation and long life.
The Eveready Advantage
5 step electrical protection for improved life & performance.Potted drivers across wattages for zero failures during instances of vibration.Specially designed heat sink for better LED and luminaire life.Anti vibration rubber & eye bolt-nut along with counter pin is given with cradle for easy and vibration free installation.Non yellowing type secondary optics for better light distribution & control.
Features
5 step electrical protection for improved life & performance.Potted drivers across wattages for zero failures during instances of vibration.Specially designed heat sink for better LED and luminaire life.Anti vibration rubber & eye bolt-nut along with counter pin is given with cradle for easy and vibration free installation.Non yellowing type secondary optics for better light distribution & control.
Specifications
| Housing & Finish | Pressure die-cast Aluminium |
| Power Factor | ≥ 0.9 |
| Total Harmonic Distortion | ≤ 10% (>8W) & ≤ 15% (4W & 8W) |
| Surge Protection | Up to 2.5kV |
| Input Voltage | 240V 50Hz |
| Operating Voltage Range | 150V - 260V AC |
| Average life span at L70B50 | 20000 |
| Operating Temperature | -10℃ to +50℃ |
| Mounting arrangement | Recess |
| Ingress protection & Impact resistance | IP20, IK03 |
Product Ordering Details
| Ordering Code | Product Cat Ref | Input Power (W) | CCT | CRI | Luminous Flux (Lumens) | Case Lot | Weight |
|---|---|---|---|---|---|---|---|
| 6DA2308C808 | LEDDNC008I3-01 | 8 | 3000K | >80 | 720 | 20 | 0.09 |
| 6DA2408C808 | LEDDNC008I4-01 | 8 | 4000K | >80 | 800 | 20 | 0.09 |
| 6DA2308C812 | LEDDNC012I3-01 | 12 | 3000K | >80 | 1080 | 20 | 0.17 |
| 6DA2408C812 | LEDDNC012I4-01 | 12 | 4000K | >80 | 1200 | 20 | 0.17 |
| 6DA2308C815 | LEDDNC015I3-01 | 15 | 3000K | >80 | 1350 | 20 | 0.38 |
| 6DA2408C815 | LEDDNC015I4-01 | 15 | 4000K | >80 | 1500 | 20 | 0.38 |
| 6DA2308C820 | LEDDNC020I3-01 | 20 | 3000K | >80 | 1800 | 20 | 0.38 |
| 6DA2408C820 | LEDDNC020I4-01 | 20 | 4000K | >80 | 2000 | 20 | 0.38 |
| 6DA2308C830 | LEDDNC030I3-01 | 30 | 3000K | >80 | 2700 | 20 | 0.63 |
| 6DA2408C830 | LEDDNC030I4-01 | 30 | 4000K | >80 | 3000 | 20 | 0.63 |
Raise a Query
Due To Continuous Technological Improvements And Design Requirements, Our Products Are Subject To The Up-Gradation Which May Result In Change Of Design, Shape, And Technical Data As Appearing. Please Connect With Our Authorized Dealer Or Sales Person For Latest Lighting Solutions.
