Hilite L 10W
Featuring new generation COB LED technology, these downlights have a thin trim deep recessed light source. They are made with a pressure die cast housing and incorporate innovative optics that direct light to desired areas. Angled heatsink helps to maintain thermal of the product also it enhances the aesthetic appeal.
The Eveready Advantage
COB downlight with angled heatsink allows installation in low height ceilings while maintaining smaller profile.The compact yet sturdy housing design enables glare-free illumination and optimal light output.These downlights are available in warm white, neutral white and cool white.Dimable analog/dali option available.
Features
COB downlight with angled heatsink allows installation in low height ceilings while maintaining smaller profile.The compact yet sturdy housing design enables glare-free illumination and optimal light output.These downlights are available in warm white, neutral white and cool white.Dimable analog/dali option available.
Specifications
| Housing & Finish | Pressure die-cast Aluminium |
| Power Factor | ≥ 0.9 |
| Total Harmonic Distortion | < 20% |
| Surge Protection | Up to 2.5kV |
| Input Voltage | 240V 50Hz |
| Operating Voltage Range | 140V - 280V AC |
| Average life span at L70B50 | 20000 Hours |
| Operating Temperature | -10℃ to +45℃ |
| Mounting arrangement | Recess |
| Ingress protection & Impact resistance | IP20, IK07 |
Product Ordering Details
| Ordering Code | Product Cat Ref | Input Power (W) | CCT | CRI | Luminous Flux (Lumens) | Case Lot | Weight |
|---|---|---|---|---|---|---|---|
| On Request | LEDDNCL010I3-01 | 10 | 3000K | >85 | 1000 | 20 | 0.150 |
| On Request | LEDDNCL010I4-01 | 10 | 4000K | >85 | 1000 | 20 | 0.150 |
| On Request | LEDDNCL010I6-01 | 10 | 6500K | >85 | 1000 | 20 | 0.150 |
Raise a Query
Due To Continuous Technological Improvements And Design Requirements, Our Products Are Subject To The Up-Gradation Which May Result In Change Of Design, Shape, And Technical Data As Appearing. Please Connect With Our Authorized Dealer Or Sales Person For Latest Lighting Solutions.
