LED Flood Lights for area lighting applications are made with single piece pressure die-cast aluminium housing with dedicated heat sink and toughened glass. LEDs with secondary optics with beam angle of 30° is provided for better light distribution and control. IP66 degree of protection & impact resistance of IK-07 makes it durable & sturdy product. Top opening separate control gear compartment with Potted Driver of 5kV & 10kV external surge protection for enhanced safety features.
The Eveready Advantage
High efficacy with >120lm/W delivered.Modular pressure die cast housing for better heat dissipation.Secondary optics for better control over distribution.Access for 360 deg. rotation with mounting cradle for best possible light distribution.
Features
High efficacy with >120lm/W delivered.Modular pressure die cast housing for better heat dissipation.Secondary optics for better control over distribution.Access for 360 deg. rotation with mounting cradle for best possible light distribution.
Specifications
| Housing & Finish | PDC housing with epoxy grey powder coating finish |
| Power Factor | ≥ 0.95 |
| Total Harmonic Distortion | ≤ 10% |
| Surge Protection | upto 5KV inbuilt and 10KV external |
| Input Voltage | 240V 50Hz |
| Operating Voltage Range | 140V - 280V AC |
| Average life span at L70B50 | 50000 |
| Operating Temperature | -10℃ to +50℃ |
| Mounting arrangement | Bracket mounting with cradle |
| Ingress protection & Impact resistance | IP66, IK07 |
Product Ordering Details
| Ordering Code | Product Cat Ref | Input Power (W) | CCT | CRI | Luminous Flux (Lumens) | Case Lot | Weight |
|---|---|---|---|---|---|---|---|
| 6F57PBH7250 | LEDFL250I5-03H | 250 | 5700K | >70 | 30000 | 1 | 7.4 |
| 6F57PBH7300 | LEDFL300I5-03H | 300 | 5700K | >70 | 36000 | 1 | 7.5 |
| 6F57PBH7350 | LEDFL350I5-03H | 350 | 5700K | >70 | 42000 | 1 | 11.5 |
| 6F57PBH7400 | LEDFL400I5-03H | 400 | 5700K | >70 | 48000 | 1 | 11.5 |
| 6F57PBH7500 | LEDFL500I5-03H | 500 | 5700K | >70 | 60000 | 1 | 15.75 |
