Easylite LED Aluminium (AL) Batten With Sensor
Industrial box type luminaire made in CRCA housing with single & twin LED tube mounting options. Inbuild wiring with connector provided for safe and secure connection.
The Eveready Advantage
Easylite AL batten with compact design with decorative end caps.Smart Sensor detects motion and turns on to full mode and dimming mode accordingly.High performance injection moulded non yellowing type diffuser for spot free lighting.Detection Angle Coverage of 150˚ and Sensing Distance 2-6 meter.
Features
Easylite AL batten with compact design with decorative end caps.Smart Sensor detects motion and turns on to full mode and dimming mode accordingly.High performance injection moulded non yellowing type diffuser for spot free lighting.Detection Angle Coverage of 150˚ and Sensing Distance 2-6 meter.
Specifications
| Housing & Finish | Aluminium Extrusion with White finish |
| Power Factor | ≥ 0.95 |
| Total Harmonic Distortion | ≤ 15% |
| Surge Protection | Up to 2.5kV Inbuilt |
| Input Voltage | 240V 50Hz |
| Operating Voltage Range | 140V - 300V AC |
| Average life span at L70B50 | 25000 Hours |
| Operating Temperature | -10℃ to +50℃ |
| Mounting arrangement | Surface |
| Ingress protection & Impact resistance | IP20, IK05 |
Product Ordering Details
| Ordering Code | Product Cat Ref | Input Power (W) | CCT | CRI | Luminous Flux (Lumens) | Case Lot | Weight |
|---|---|---|---|---|---|---|---|
| 6B65PAM8010 | LEDBTA020I6-01 | 10 | 6500K | >80 | 1000 | 20 | 0.090 |
| 6B65PAA8020 | LEDBTA020I6-02 | 20 | 6500K | >80 | 2000 | 20 | 0.22 |
| 6B65PAM8040 | LEDBTA040I6-01 | 40 | 6500K | >80 | 4000 | 20 | 0.30 |
| 6B65PAAD020 | LEDBTA020I6-SD | 20 | 6500K | >80 | 2000 | 20 | 0.32 |
Raise a Query
Due To Continuous Technological Improvements And Design Requirements, Our Products Are Subject To The Up-Gradation Which May Result In Change Of Design, Shape, And Technical Data As Appearing. Please Connect With Our Authorized Dealer Or Sales Person For Latest Lighting Solutions.
